Vehículos de movilidad personal

ELECTRIC SCOOTER WITH REMOVABLE BATTERY

Resumen de: US2024399920A1

Various electric scooters are disclosed that include a battery receptacle configured to releasably retain a rechargeable battery therein. The electric scooter may include a deck and a strut extending between the deck and a rotatable shaft connected to a handlebar assembly. The battery receptacle may be supported by the strut, and the battery may be insertable into and removed from the battery receptacle through translation of the battery in a direction substantially parallel to a longitudinal axis of the strut. The battery may be configured for use in a power tool in addition to the electric scooter.

A DISTRIBUTED REAL-TIME MACHINE LEARNING ROBOT

Resumen de: US2024383560A1

An autonomous driving robot based on a two-wheel SEGWAY self-balancing scooter. Sensors including LiDAR, camera, encoder, and IMU were implemented together with digital servos as actuators. The robot was tested simultaneously with the functionality features including obstacle avoidance based on fuzzy logic and 2D grid map, data fusion based on co-calibration, 2D simultaneously localization and mapping (SLAM) and path planning under different scenarios both indoor and outdoor. As a result, the robot initially has the ability of self-exploration with avoiding obstacles and constructing 2D grid map simultaneously. A simulation of the robot with same 10 functionalities except data fusion has also been tested and performed based on robot operating system (ROS) and Gazebo as the simple comparison of the robot in real world.

FOLDABLE MOBILITY SCOOTER

Resumen de: EP4458656A1

The present invention relates to an electric scooter, and in particular to a foldable scooter. A foldable scooter is provided, comprising a front frame and a rear frame, wherein the front frame comprises a front fixation portion, and a first connecting frame and a second connecting frame which extend longitudinally; the front and rear ends of the first connecting frame are oppositely located above the front and rear ends of the second connecting frame; the rear frame comprises a rear fixation portion, and a third connecting frame and a fourth connecting frame which extend longitudinally; both the front end of the first connecting frame and the front end of the second connecting frame are fixed to the front fixation portion in a rotatable manner; the front end of the third connecting frame is fixed to the rear end of the first connecting frame in a rotatable manner, the third connecting frame deviating from its end is fixed to the rear end of the second connecting frame in a rotatable manner, and the rear end of the third connecting frame is connected to the rear fixation portion; and, the rear end of the fourth connecting frame is fixed to the third connecting frame or the rear fixation portion in a rotatable manner, while the rear end thereof is fixed to the first connecting frame in a rotatable manner. The present invention has the advantage that the folded scooter occupies less space and is more convenient for storage and transportation.

FREEWHEELING ELECTRIC SCOOTER

Resumen de: US2024359763A1

Various personal mobility vehicles, such as scooters, are disclosed. The scooter can include at least one battery and motor for powering at least one driven wheel. The vehicle can include a gear assembly to convert a torque produced by the motor to a different torque to a driven shaft to power the at least one driven wheel. The battery can be removable.

ELECTRIC SCOOTER PROVIDED WITH A GEARBOX

Resumen de: US2024359774A1

Electric scooter having: a footboard; at least one driving wheel that is coupled to the footboard and is arranged in a front or rear position; at least one driven wheel which is coupled to the footboard and is arranged in a rear or front position; a handlebar operatively coupled to the footboard to turn a front wheel; an electric motor that is suitable for turning the driving wheel; and a gearbox with two or more gear ratios that is interposed between the electric motor and the driving wheel to receive the motion from the electric motor and transmit motion to the driving wheel.

BALANCE ASSISTANCE AND FIREPROOFING DEVICE FOR SCOOTERS

Resumen de: WO2024220862A1

Disclosed herein are exemplary devices that provide balance assistance and fireproofing to electric scooters. The devices described herein can be clipped onto existing scooters, providing balance improvements via one or more training wheels and providing fireproofing improvements via one or more units containing fire-suppressant materials. A device may be attached to the center of a scooter's standing platform to improve the stability of the scooter and to provide fireproofing to the batteries. The device can include two training wheels, each positioned to an opposite side of the standing platform, to provide the vehicle with stability. The training wheels may be connected to an axle that is mounted to a fireproofing unit. The fireproofing unit, which contains fire-suppressant materials, can clamp to the standing platform, which contains at least a portion of the batteries. Users can adjust, reposition, and/or remove portions of the balance assistance and fireproofing device.

BALANCE ASSISTANCE AND FIREPROOFING DEVICE FOR SCOOTERS

Resumen de: US2024351659A1

Disclosed herein are exemplary devices that provide balance assistance and fireproofing to electric scooters. The devices described herein can be clipped onto existing scooters, providing balance improvements via one or more training wheels and providing fireproofing improvements via one or more units containing fire-suppressant materials. A device may be attached to the center of a scooter's standing platform to improve the stability of the scooter and to provide fireproofing to the batteries. The device can include two training wheels, each positioned to an opposite side of the standing platform, to provide the vehicle with stability. The training wheels may be connected to an axle that is mounted to a fireproofing unit. The fireproofing unit, which contains fire-suppressant materials, can clamp to the standing platform, which contains at least a portion of the batteries. Users can adjust, reposition, and/or remove portions of the balance assistance and fireproofing device.

MULTIFUNCTION ELECTRIC SCOOTER WITH VARIABLE CONFIGURATION

Resumen de: CN118382578A

The invention relates to a multifunctional scooter (1) comprising: a frame (10); a front wheel (20) and two rear wheels (30), which rotate on axes (21, 32) parallel to each other and are mounted on the frame (10); a platform (40); a handlebar (50) connected to the at least one front wheel (20); an electric motor (60) having a corresponding power supply device mounted on the frame (10); a propeller (80) mounted on the frame (10); and coupling means adapted to selectively couple the at least one motor (60) with the at least one rear wheel (30) or with the at least one propeller (80).

Electric scooter without wiring of vertical pipe

Resumen de: CN118701203A

The electric scooter comprises a bearing unit, an operation unit, a power output device, a vehicle speed control device, a power source and other electronic devices, no wiring is arranged on the operation unit, the power output device, the vehicle speed control device, the power source and the other electronic devices are all arranged on the bearing unit, and the operation unit comprises a vertical pipe and a handle. The bearing unit comprises a frame, a front wheel and a rear wheel, a wheel connecting piece is arranged on the front side of the frame, a connecting mechanism is arranged between the vertical pipe and the wheel connecting piece and comprises an upper connecting seat, a lower connecting seat and two spring pin shafts, upper connecting holes are formed in the front side and the rear side of the upper connecting seat, and lower connecting holes are formed in the front side and the rear side of the lower connecting seat; the upper connecting holes and the lower connecting holes on the same side form connecting shaft holes, the two spring pin shafts penetrate through the front connecting shaft hole and the rear connecting shaft hole to be connected with the upper connecting base and the lower connecting base respectively, and the operating unit and the bearing unit are folded or separated by pulling out one or two spring pin shafts.

Shared battery type electric scooter

Resumen de: CN118683669A

The invention discloses a shared battery type electric scooter. The shared battery type electric scooter comprises an electric scooter body, a battery module detachably installed on the electric scooter body and charging cabinets arranged at the positions of rail transit stations. The electric scooter comprises a pedal, a front wheel, a rear wheel, an operating rod and a motor assembly, the front wheel and the rear wheel are arranged at the two ends of the pedal, the operating rod is arranged on the pedal, the motor assembly is used for driving the front wheel and/or the rear wheel, a connecting piece is arranged between the pedal and the operating rod, the operating rod is rotationally matched with the connecting piece, and the front end of the pedal is hinged to the connecting piece so that the pedal can be in a folded state and an unfolded state; the charging cabinet is provided with a plurality of containing cavities used for containing the battery modules, the containing cavities are arranged to charge the battery modules after the battery modules are inserted into the containing cavities, and the battery modules are allowed to be taken and placed after authorization permission is obtained. The invention provides a shared battery type electric scooter. According to the shared battery type electric scooter, people can take urban rail transit without being affected in the process of using the electric scooter.

Anti-skid electric scooter

Resumen de: CN221757665U

The utility model provides an anti-skid electric scooter which comprises a scooter body, the scooter body comprises a supporting seat, a connecting seat is fixed to one end of the supporting seat, a rotating column is rotationally installed on the connecting seat, a supporting frame is fixed to the bottom of the rotating column, a guide wheel is rotationally installed in the supporting frame, and the guide wheel is connected with the connecting seat. A mounting seat is fixed on the other side of the supporting seat, a moving mechanism is mounted between the mounting seats, a fixing groove is formed in the supporting seat, an anti-skid plate is movably mounted in the fixing groove, a limiting assembly is rotatably mounted on the side of the supporting seat, and the limiting assembly is matched with the anti-skid plate. According to the anti-skid electric scooter, in the later period of use, the foot treads on the anti-skid plate to apply pressure, the anti-skid plate moves downwards by a certain distance through the connecting plate, the anti-skid plate and the fixing groove are staggered up and down, secondary anti-skid limiting is achieved for the foot through the height difference after up-down staggering, and therefore anti-skid use is effectively achieved.

Dual-purpose electric scooter

Resumen de: CN221698872U

The utility model relates to the field of scooters, and discloses a dual-purpose electric scooter which comprises a frame, a supporting plate is arranged on the frame, and a seat plate and an overturning limiting mechanism for driving the seat plate to overturn to be attached to the supporting plate or to be overturned to be unfolded to limit the seat plate are arranged on the supporting plate. The two ends of the connecting rod are hinged to the two sides of the bearing plate and the two sides of the seat plate respectively, the limiting part limits the connecting rod to rotate relative to the bearing plate after the seat plate is unfolded, the traction component is arranged at the end of the seat plate and connected with a frame when the seat plate is unfolded, and the end of the connecting rod is hinged to the position, close to the traction component, of the side wall of the seat plate. The two ends of the seat plate form a lever with the hinged position of the seat plate and the connecting rod as a fulcrum, the end, away from the traction component, of the lever acts on the traction component and the scooter frame when the end of the lever is subjected to gravity, downward overturning of the seat plate is limited, the electric scooter can be switched between the mode with a seat and the mode without the seat to achieve different riding modes, and more riding choices can be provided for people.

Electric scooter with storage basket

Resumen de: CN221698905U

The utility model discloses an electric scooter with a storage basket, which comprises an electric scooter and a handlebar, a moving component is mounted on the electric scooter, the moving component comprises a front wheel and a rear wheel, a lifting component is mounted at the bottom of the handlebar, the lifting component comprises a support sleeve and a support rod, a fixing component is mounted on the support sleeve, and the support rod is mounted on the fixing component. The electric scooter with the storage basket comprises a fixing assembly, the fixing assembly comprises a pin hole and a clamping pin, a storage assembly is installed on the electric scooter and comprises an inner sleeve and an outer sleeve, and a protection assembly is installed at the top of the outer sleeve. Meanwhile, a person can sit on the seat plate during riding and does not need to stand on the electric scooter for a long time, manpower is saved, the comfort of the person during traveling is improved, it is guaranteed that the height of the seat plate and the height of the handlebar are matched with the height of the person, people of different heights can use the electric scooter conveniently, and the electric scooter is suitable for being used by the person during riding.

Electric scooter with handrail lock anti-theft function

Resumen de: CN221660872U

The utility model discloses an electric scooter with a handrail lock anti-theft function. The electric scooter comprises a folding vertical rod assembly, a handrail lock body and a lock rope fixing seat. The handrail lock body is fixedly connected with the folding vertical rod assembly, and the lock rope fixing seat is arranged below the handrail lock body; the lock rope fixing seat is fixedly connected with the folding vertical rod assembly; a lock rope containing cavity is formed in the folding vertical rod assembly, the lower end of the lock rope extends out of the folding vertical rod assembly through a lock rope hole of the handrail lock body, and the upper end of the lock rope is arranged to be limited in the folding vertical rod assembly. The lower end of the lock rope is connected with a lock; the handrail lock body comprises a lock cylinder and a locking opening, the lock cylinder is provided with a lock block at the locking opening, and when the lock rope is inserted into the locking opening, the lock block has a locking state capable of being matched with the lock head and an opening state capable of achieving mutual separation of the lock block and the lock head through the unlocking button. According to the technical scheme, the problem that the scooter is lost can be effectively solved.

ELECTRIC SCOOTER ASSEMBLIES

Resumen de: US2024294226A1

In some embodiments, an electric scooter comprises a deck configured to support a rider, front and rear wheels, a handlebar assembly that includes a handlebar, a left handle, and a right handle, a steering column that includes a steering tube and the handlebar assembly, and an electric motor configured to provide mechanical power to at least one of the front and the rear wheels. One or more of the steering column, steering tube, handlebar assembly, handlebar, left handle, right handle, and deck can be configured to be detachable and comprise one or more rechargeable battery packs. In addition, one or more of the steering column, steering tube, handlebar assembly, handlebar, left handle, right handle, and deck can be configured to receive one or more removable rechargeable batteries.

Pedal structure and electric scooter

Resumen de: CN221642612U

The utility model provides a pedal structure and an electric scooter, and belongs to the technical field of scooters. The pedal structure comprises a frame bottom beam, two pedals, two first pins, a trigger piece and two first driving pieces; the two pedals are respectively connected to the frame bottom beam through torsional spring shafts; the two first pins are respectively arranged on the two pedals; the trigger piece is arranged on the frame bottom beam and used for pushing the first pin, so that the first pin is inserted into a first hole formed in the frame bottom beam, and the pedal is kept in an unfolded state; the two first driving parts are arranged on the two pedals respectively, each first driving part is connected with one first pin and used for driving the first pin to retreat from the first hole, and therefore the pedals are overturned to be in the retracting state under the action of torque generated by the torsional spring shaft. By means of the pedal structure, the technical problem that in the prior art, pedal states of a scooter are inconvenient to switch can be solved.

Scooter with detachable battery pack

Resumen de: CN221642607U

The scooter comprises a handle, the battery pack and a pedal, a battery cavity position is arranged at the lower end of the pedal, the battery pack is inserted into the battery cavity position, a battery inserting plate is arranged at the front end of the battery cavity position, a positive electrode plate and a negative electrode plate are inserted into the battery pack, and a charging interface and a power switch are installed below the pedal. The handle and the pedal are detachable, and a scooter starting key is installed at the upper end of the handle. According to the scooter with the detachable battery pack, the battery pack convenient to mount and dismount is adopted for power supply connection, a special battery is not needed any more, the battery pack can be automatically replaced, a non-electric scooter is formed after the battery pack is dismounted, a handle for controlling the scooter to move can be dismounted, wireless control is carried out through remote Bluetooth, and the scooter becomes a three-wheel remote control sliding plate; three purposes are achieved, the charging port is designed below the pedal, charging is convenient, meanwhile, the motor shaft of the brushless motor used for driving the rear wheel is locked on the two sides of the pedal in the radial direction, and the structure is more stable compared with an axial locking structure.

Charging method and device, electric scooter and storage medium

Resumen de: CN118544845A

The invention relates to a charging method and device, an electric scooter and a storage medium, the method is applied to the electric scooter which is provided with a battery and is configured with a preset communication protocol, and the method comprises the steps that in the charging process that the battery is configured with a charger of the preset communication protocol, state parameters of the battery are obtained, the state parameters comprise at least one of battery voltage, battery current and battery temperature; according to the state parameters, corresponding charging parameters are determined, and the charging parameters comprise charging current and/or charging voltage; and generating a first charging request according to the charging parameter, and sending the first charging request to the charger through the preset communication protocol, so that the charger charges the battery according to the charging parameter.

Electric scooter easy to store

Resumen de: CN221605982U

The utility model relates to the technical field of scooters, and discloses an electric scooter easy to store, which comprises a telescopic handlebar, a rolling front wheel is mounted at the bottom end of the telescopic handlebar, and a standing plate convenient folding component is arranged on the side edge of the telescopic handlebar. A standing plate convenient folding assembly is arranged on the side edge of the telescopic handlebar, and the standing plate convenient folding assembly and the telescopic handlebar are connected through an arranged front side fixing connecting plate. A user can pull a pull connecting plate in the standing plate convenient folding assembly, so that a first standing plate and a second standing plate are rotationally connected only through a rotating hinge shaft, the overall occupied space of the standing plate convenient folding assembly is greatly reduced, and the user can fold the standing plate convenient folding assembly by retracting a telescopic handlebar. The scooter can be folded as much as possible, so that a user can conveniently store the scooter, and the scooter can be conveniently stored and used by the user.

Electric scooter frame with good shock absorption effect

Resumen de: CN221563322U

The utility model discloses an electric scooter frame with a good shock absorption effect, and relates to the technical field of scooter frames. The scooter comprises a scooter frame body, the front side of the scooter frame body is fixedly connected with a front wheel steering column support, the rear side of the scooter frame body is movably connected with a rear wheel support through a hinge shaft, the top of the rear wheel support is fixedly provided with a lower support, and the scooter frame body above the lower support is fixedly provided with an upper support. And a shock absorber is arranged between the lower support and the upper support. According to the electric scooter, the rear side of the scooter frame body is movably connected to the rear wheel support, and the shock absorber is arranged between the rear wheel support and the scooter frame body, so that certain shock absorption can be carried out on the scooter frame in the moving process of the electric scooter, the scooter frame can be more stable when passing through the road surface, and the service life of the scooter is prolonged. The side baffles are arranged on the two sides of the shock absorber, so that large soil can be prevented from being directly thrown on the shock absorber, and the adverse effect on the shock absorption effect of the shock absorber is avoided.

Scooter with detachable battery

Resumen de: CN221519887U

The scooter comprises a handle and a pedal, the handle is installed at the front end of the pedal, the lower end of the pedal is provided with a battery cavity position, a rechargeable battery is placed in the battery cavity position and is detachable, a cavity position opening is formed below the battery cavity position, and a battery cover plate covers the cavity position opening. A control panel is installed in the pedal, a charging interface and a power switch are installed below the pedal, the charging interface is electrically connected with the control panel, the power switch is in signal connection with the control panel, and a scooter starting key is installed on the front portion of the upper end of the pedal. According to the scooter with the detachable battery, the battery can be easily detached from the lower portion of the pedal, a non-electric scooter is formed after the battery is detached, one scooter has two purposes, a charging port is designed to be hidden below the pedal, charging is convenient, the use experience is improved, meanwhile, a motor shaft of a brushless motor used for driving a rear wheel is locked on the two sides of the pedal in the radial direction, and the service life of the scooter is prolonged. Compared with an axial locking structure, the locking structure is more stable.

Novel damping type monocycle

Resumen de: CN118478972A

The invention discloses a novel damping type monocycle. The U-shaped supports are installed on the two sides of the hub motor, the rack is installed on the U-shaped supports in a lifting mode, the elastic body is installed in the middle between the rack and the U-shaped supports, the battery box controller is installed on the top of the rack, and the pedal plates are installed at the lower ends of the two sides of the rack in a turnover mode. Therefore, the hub motor, the U-shaped support, the rack, the elastic body, the battery box controller and the pedals are combined to form the wheelbarrow, the elastic body of the wheelbarrow is arranged in the middle position between the U-shaped support and the rack, and compared with the mode that a traditional wheelbarrow is arranged on the two sides in a damping mode, the number of parts is reduced, and the assembling process is simplified; the production cost is reduced; meanwhile, the elastic body can be adjusted according to the actual bearing condition so as to adjust the damping performance; in addition, the whole unicycle is small in size, light in weight and convenient to transport and store.

Electric scooter frame with detachable cover plate

Resumen de: CN221519870U

The utility model discloses an electric scooter frame with a detachable cover plate, and relates to the field of single vehicles. An electric scooter frame with a detachable cover plate comprises a scooter frame body and a scooter foot support, the detachable cover plate is installed on the upper surface of the scooter frame body, the scooter foot support is arranged on one side of the scooter frame body, a cover plate rotary knob is arranged on the surface of the detachable cover plate, and the cover plate rotary knob penetrates through the detachable cover plate to be connected with the scooter frame body. A partition plate is fixedly connected in the scooter frame, a battery bin is arranged in the scooter frame, a driving motor bin is additionally arranged in the scooter frame, and the battery bin and the driving motor bin are separated through the partition plate. According to the electric scooter, the battery bin is arranged in the scooter frame, the upper wall of the electric scooter is replaced by the detachable cover plate, the cover plate knob is arranged, and the cover plate knob is connected with the scooter frame, so that the technical problem that an existing product on the market is tedious in battery replacement and disassembly is solved.

Scooter with detachable handle

Resumen de: CN221519886U

The scooter comprises the handle and a pedal, the handle is installed at the front end of the pedal, the lower end of the pedal is provided with a battery cavity position, a rechargeable battery is placed in the battery cavity position and is detachable, a cavity position opening is formed below the battery cavity position, and a battery cover plate covers the cavity position opening. A charging interface and a power switch are installed below the pedal, the lower end of the handle is in bolted connection with the front end of the pedal, and the handle and the pedal are detachable. According to the scooter with the detachable handle, a battery can be easily detached from the lower portion of the pedal, a non-electric scooter is formed after the battery is detached, the handle for controlling the scooter to move is detached, wireless control is conducted through remote Bluetooth, the scooter is changed into a three-wheel remote control sliding plate, three purposes are achieved through one scooter, a charging port is designed to be hidden below the pedal, charging is convenient, and the scooter is convenient to use. Meanwhile, the motor shaft of the brushless motor used for driving the rear wheel is locked on the two sides of the pedal in the radial direction, and compared with an axial locking structure, the structure is more stable.

Electric scooter

Nº publicación: CN221519903U 13/08/2024

Solicitante:

ZHONGKE MITHUANG SUZHOU HEALTH TECH CO LTD
\u4E2D\u79D1\u4F8E\u521B\uFF08\u82CF\u5DDE\uFF09\u5065\u5EB7\u79D1\u6280\u6709\u9650\u516C\u53F8

Resumen de: CN221519903U

The utility model discloses an electric scooter, which belongs to the field of electric scooters, and comprises a wheel component, a handlebar component, a vehicle underframe component, a vehicle seat component, a connecting component and a locking component, the wheel component comprises a front wheel and a rear wheel, and the handlebar component is foldably mounted on the front side of the vehicle underframe component. The handlebar assembly drives the front wheel to do steering motion and drives the rear wheel to do steering motion, a limiting groove is formed in one side of the seat assembly, the locking assembly comprises a limiting pin, the limiting pin is arranged on the seat assembly and located below the seat assembly, the length direction of the limiting groove is perpendicular to the axial direction of the limiting pin, and the connecting assembly comprises a limiting nut and a connecting rod. One end of the connecting rod is connected with the vehicle underframe assembly, the other end of the connecting rod is provided with a limiting nut, and the limiting pin and the limiting nut are clamped and matched to achieve locking. The electric scooter can be folded, meanwhile, the folded electric scooter is small in size, convenient to store and transport, relatively simple in structure and low in cost.
