Vehículos de movilidad personal

Electric scooter that can be used as a mobile cart or stroller

Resumen de: KR20240120026A

본 발명은 이동카트 또는 유모차 겸용으로 사용할 수 있는 전동스쿠터에 관한 것이다. 본 발명에 따른 이동카트 또는 유모차 겸용으로 사용할 수 있는 전동스쿠터는, 상하로 연장되는 핸들프레임과 핸들프레임 상단에 결합되는 핸들을 포함하여 구성되는 핸들조작부; 핸들프레임에 결합되는 제11몸체와 일단이 제11몸체에 결합되고 타단은 후방으로 연장되는 제12몸체로 구성되는 제1몸체; 일단이 제12몸체에 힌지 결합되고 타단은 후방으로 연장되는 제21몸체와 제21몸체에 결합되는 안장부를 포함하여 구성되는 제2몸체; 일단이 제21몸체 후부에 힌지 결합되는 제31몸체와 제31몸체 타단에 결합되는 후륜으로 구성되는 제3몸체; 가운데 부위가 핸들프레임 하단 또는 제11몸체 하부에 결합되고 양 끝단은 양 측방으로 연장되는 전륜프레임과 전륜프레임 양 끝단에 결합되는 전륜으로 구성되는 전륜부; 제1몸체 또는 제2몸체에 결합되는 발판부; 제2몸체 후부에 결합되는 구름바퀴프레임과 구름바퀴프레임에 결합되는 구름바퀴로 구성되는 구름바퀴부; 및 제1몸체와 제2몸체 및 제3몸체 중 어느 한 부위에 결합과 분리할 수 있게 구성되는 탑재부; 를 포함하여 구성되는 전동스쿠터가 이동카트 또는 유모차로 변신하면 제3몸체가 제2몸체

Scooter with battery convenient to replace

Resumen de: CN221477376U

The utility model relates to the technical field of electric scooters, in particular to a scooter with a battery convenient to replace, which comprises a hollow frame, a control module arranged in a hollow space of the frame and a battery component inserted in the hollow space of the frame. The battery assembly comprises a protective shell, a first locking structure arranged in the protective shell and a battery body arranged in the protective shell, and the battery body can be electrically connected with the control module; the first locking structure comprises a mounting seat arranged on the inner wall of the protective shell, an elastic piece arranged on the mounting seat and a locking piece which sequentially protrudes out of the protective shell and the frame; the locking piece can abut against the inner wall of the elastic piece and the inner wall of the protective shell. The battery assembly is convenient and fast to replace, the battery assembly can be disassembled by hands through unlocking and locking of the first locking structure, a disassembling tool is not needed, and the disassembling and assembling steps of the battery assembly are simplified. The first locking structure is compact in structure and small in space occupancy rate.

Walking type electric scooter

Resumen de: CN221418504U

The utility model relates to a hand-held electric scooter, the electric scooter adopts a film pressure sensor to control motion, the electric scooter comprises a pedal part, a front wheel, a rear wheel, a support and a hand-held rod, the front wheel is connected to the support, the hand-held rod is connected to the support, the rear wheel is rotatably connected to a main body of the electric scooter, and the front wheel is connected to the support. A lifting mechanism is arranged between the handrail and the support, the bottom of the support is rotationally connected with the wheel carrier, the front wheel is rotationally connected to the wheel carrier, the wheel carrier is rotationally connected with the electric scooter body through a bearing, and a limiting assembly is arranged between the bottom of the support and the wheel carrier. Through the design of the lifting mechanism and the limiting assembly, the height of the handrail rod can be adjusted through the lifting mechanism so as to adapt to people with different heights, the use range is greatly widened, use is more flexible and convenient, and storage and transportation are convenient.

Folding electric scooter frame

Resumen de: CN118387226A

The invention relates to the technical field of electric scooters and discloses a folding electric scooter frame which comprises a frame body, a baffle is fixedly connected to the top of the frame body, a positioning frame is fixedly connected to the top of the frame body, an inclined frame is rotatably connected to the inner wall of the positioning frame, and a supporting rod is fixedly connected to the end, away from the positioning frame, of the inclined frame. The bottoms of the supporting rods are fixedly connected with roller frames, and the tops of the supporting rods are fixedly connected with holding rods. After an operator steps on the surface of a pressure part, the pressure part pushes a pressure rod to move downwards through connection of a linkage plate and a connecting plate, the pressure rod makes contact with the inner wall of a groove disc when moving downwards and extrudes the groove disc to move downwards, and an inclined frame is pulled to move downwards when the groove disc moves downwards; at the moment, the inclined frame extrudes the rollers through the connection of the supporting rods and the roller frames, so that the riding stability of an operator is improved, the supporting rods and the holding rods are extruded and fixed through the weight of the operator, and the convenience of the frame during installation is improved.

Multifunctional electric scooter with variable configuration

Resumen de: CN118382578A

The invention relates to a multifunctional scooter (1) comprising: a frame (10); a front wheel (20) and two rear wheels (30), which rotate on axes (21, 32) parallel to each other and are mounted on the frame (10); a platform (40); a handlebar (50) connected to the at least one front wheel (20); an electric motor (60) having a corresponding power supply device mounted on the frame (10); a propeller (80) mounted on the frame (10); and coupling means adapted to selectively couple the at least one motor (60) with the at least one rear wheel (30) or with the at least one propeller (80).

Electric scooter

Resumen de: CN221316522U

The utility model discloses an electric scooter. The electric scooter comprises a handlebar, a front wheel assembly, a pedal, a rear wheel assembly, a battery cell and a controller. A mounting cavity is formed in the rear portion of the pedal and provided with an opening facing backwards. The rear wheel assembly comprises a rear fork, a rear wheel and a damping mechanism, the first end of the rear fork extends into the mounting cavity from the opening and is in pivot joint with the pedal, the damping mechanism is arranged in the mounting cavity, the first end of the damping mechanism is in pivot joint with the first end of the rear fork, the pivot joint position of the rear fork and the pedal is a first position, and the pivot joint position of the rear fork and the damping mechanism is a second position. The first position is higher than the second position; the rear wheel is arranged at the second end of the rear fork. According to the utility model, the damping mechanism is mounted in the mounting cavity, and the rear fork part extends into the mounting cavity, so that the damping mechanism is positioned in a relatively enclosed environment, most of dust can be isolated, the situation that the damping mechanism is contaminated by the dust is reduced, the damping mechanism can be kept in a clean state for a long time, and the cleaning frequency of the damping mechanism is reduced; and the maintenance cost of the electric scooter is reduced.

Motor For Unicycle And Unicycle

Resumen de: US2024227968A1

A motor for a unicycle includes a motor main shaft, a stator mechanism disposed on the motor main shaft, and a rotor mechanism disposed on the motor main shaft. The motor includes a bearing sleeved on the motor main shaft, and the rotor mechanism is connected with the motor main shaft through the bearing, and the stator mechanism includes a stator support, and an electric core mechanism is disposed on the stator support. Since the electric core mechanism is disposed on the stator mechanism, and the stator mechanism and the electric core mechanism are integrated together, an overall compact structure of the motor is realized. Moreover, the electric core mechanism is disposed on the stator support, effectively ensuring that the electric core mechanism is integrated in the motor without affecting the normal rotation of the motor, and further providing a good protection for the electric core mechanism.

MOTOR FOR UNICYCLE AND UNICYCLE

Resumen de: EP4398455A1

A motor for a unicycle includes a motor main shaft, a stator mechanism disposed on the motor main shaft, and a rotor mechanism disposed on the motor main shaft. The motor includes a bearing sleeved on the motor main shaft, and the rotor mechanism is connected with the motor main shaft through the bearing, and the stator mechanism includes a stator support, and an electric core mechanism is disposed on the stator support. Since the electric core mechanism is disposed on the stator mechanism, and the stator mechanism and the electric core mechanism are integrated together, an overall compact structure of the motor is realized. Moreover, the electric core mechanism is disposed on the stator support, effectively ensuring that the electric core mechanism is integrated in the motor without affecting the normal rotation of the motor, and further providing a good protection for the electric core mechanism.

A CONVENIENT FOLDING STRUCTURE FOR ELECTRIC SCOOTERS (Machine-translation by Google Translate, not legally binding)

Resumen de: ES1309116U

Folding structure for electric scooters, comprising a folding component (2) connected between the handlebar (1) and the front fork (3) characterized in that the folding component (2) includes an upper joint (6) and a lower joint (7), where the upper joint (6) is connected at the upper end of the lower joint (7) by a pin (8) and can rotate around the pin (8) in the lower joint (7); wherein the front side of the upper joint has a first engagement groove (13) and the front side of the lower joint has a second engagement groove (14); and because on the front side a locking clasp (4) is connected that can be moved by rotating in the lower joint (7), where said locking clasp (4) includes a screw (10), the front end of which is connected with a closure C-shaped (5) that can rotate around the screw (10) as an axis, which C-shaped lock (5) can be separated or connected with the joints (6, 7) through the rotary movement of the locking clasp (4) in the lower joint (7). (Machine-translation by Google Translate, not legally binding)

Folding stand column of electric scooter

Resumen de: CN221273368U

The utility model relates to the technical field of electric scooters, in particular to an electric scooter folding stand column which comprises a stand column body and a supporting column fixedly connected with the stand column body, the supporting column body is rotationally connected with a supporting cover, the supporting cover is rotationally connected with a synchronizing shaft, the synchronizing shaft is rotationally connected with a locking plate, a sliding groove is formed in the locking plate, and a sliding hole is formed in the sliding groove. The sliding hole and the sliding groove are slidably connected with a clamping assembly, a first clamping block clamped with the clamping assembly is arranged between the stand column and the supporting column, the synchronizing shaft is further rotationally connected with a second hook plate, the supporting column is provided with a second clamping block clamped with the second hook plate, and the supporting column is provided with a positioning groove. A convex part matched with the positioning groove is arranged on the supporting cover; through precise positioning and attaching of a positioning groove and a convex part, preliminary clamping connection of a second clamping block through a second hook plate and further clamping connection of a first clamping block through a clamping connection assembly, the fastening performance of the supporting column and the supporting cover is effectively enhanced, mounting and dismounti

Headstock folding and fixing mechanism of electric scooter

Resumen de: CN221273369U

The utility model discloses an electric scooter head folding and fixing mechanism which comprises a scooter body and a scooter rod, a folding device, a first fixing device and a second fixing device are arranged between the scooter body and the scooter rod, and the first fixing device comprises a first installation seat, a second installation seat, a U-shaped rod and an insertion rod. The first mounting seat is rotatably connected with the vehicle body, the two second mounting seats are arranged on the first mounting seat, the first fixing device is arranged, after the vehicle rod and the vehicle body are folded, connection and fixation between the vehicle rod and the vehicle body can be conveniently completed through the first fixing device, and when the whole needs to be carried, the vehicle rod and the vehicle body can be conveniently fixed through the first fixing device. And the vehicle rod can be directly held by hand for carrying without worrying about scattering in the carrying process.

ELECTRIC SCOOTER BATTERY COMPARTMENT

Resumen de: EP4393801A1

An electric scooter is provided, which includes: a vehicle body component including a deck and a battery compartment mounted to the deck and includes a compartment body fixedly mounted to the deck and a compartment cover pivotally mounted to the compartment body; a front wheel component directly or indirectly fixedly mounted to one end of the vehicle body component; and a rear wheel component directly or indirectly fixedly mounted to the other end of the vehicle body component. At least one of the compartment body and the compartment cover is provided with a jacking component. When the compartment cover is closed, one end of the jacking component abuts against the compartment body, and the other end of the jacking component abuts against the compartment cover.

Electric scooter body convenient to carry

Resumen de: CN221233957U

The utility model relates to the field of electric scooters, in particular to an electric scooter body convenient to carry, which comprises a battery box, handrails are arranged on two sides of the battery box and include a left handrail and a right handrail, the length of the handrails is not larger than half of that of the battery box, the left handrail is arranged on the left side of the battery box, and the right handrail is arranged on the right side of the battery box. The left armrest is arranged at the front end of the battery box, and the right armrest is arranged at the rear end of the battery box. The problem that normal electric vehicles cannot be placed on storage racks of motor homes, sedans and other automobiles during traveling is solved, the whole vehicle body is short and small in design, the battery box body is large, the positions of a rear wheel baffle, a brake system and wiring of a power line are improved, and the storage rack is more suitable for being moved by people and stored in a small space.

Safe electric scooter

Resumen de: KR20240097537A

본 발명은 킥보드의 안전한 사용을 강제하여 탑승자의 사고 위험을 낮춘 전동 킥보드와 관련된다. 실시예로, 탑승자가 오르는 발판과 뒷바퀴가 구비된 메인프레임과, 상기 메인프레임의 전방에 회전 가능하게 구비되어 있으며 앞바퀴가 연결된 조향프레임을 구비하는 전동 킥보드에 있어서, 상기 메인프레임의 발판의 면적에 대응하여 일정 간격으로 복수가 배치되어 있으며, 탑승자의 신발로부터 가해지는 하중을 감지하는 하중감지센서와, 상기 하중감지센서의 활성을 감시하고, 이로부터 1인을 초과하여 탑승하고 있는지 여부를 판단하며, 탑승자가 1인을 초과하는 것으로 판단되면 동력 전달 수준을 평소와 다르게 제어하는 제어부를 포함하는 안전 전동 킥보드를 제시한다.

ELECTRIC SCOOTER FOLDING STRUCTURE FACILITATING PORTABILITY

Nº publicación: EP4389576A1 26/06/2024

Solicitante:

SEOJIN AUTOMOTIVE CO LTD [KR]
Seojin Automotive Co., Ltd

Resumen de: EP4389576A1

The present invention relates to a foldable structure for an easy-to-carry electric scooter comprising: an operating handle including two grips; a handle post which is attached to a lower part of the operating handle and at the bottom of which a front wheel is drivably installed; and a footrest which is connected to the bottom of the handle post at the rear of the front wheel and has a rear wheel installed at the rear end thereof, wherein the handle post has a carrying handle for hand gripping when carrying the scooter, the carrying handle being retractably built in the handle post at one side thereof; wherein the carrying handle is positioned at the front-sided width-directional center of the upper post, in order to ensure that an imaginary line connecting a support point of the front wheel in contact with the ground and a gripping point of the carrying handle passes through the center of gravity of the electric scooter, in a state of pulling out and extending the upper post from the middle post when carrying the electric scooter, and thereby the electric scooter does not rotate and remains stable even when subjected to vibrations or impacts; wherein a groove is formed in the front-sided center of the upper post into which the carrying handle is received; wherein one end of the carrying handle is hinged inside the groove such that a gripping portion of the carrying handle can be rotated and extracted; and wherein the gripping portion can be formed to include a stepped portio
